Home > Products > LED COB Down Lights > Smd 2835 CCT 536lm 5W AC COB Module

Smd 2835 CCT 536lm 5W AC COB Module

  • Smd 2835 CCT 536lm 5W AC COB Module
  • Smd 2835 CCT 536lm 5W AC COB Module
  • Smd 2835 CCT 536lm 5W AC COB Module
  • Smd 2835 CCT 536lm 5W AC COB Module

Smd 2835 CCT 536lm 5W AC COB Module

    Payment Type: L/C,T/T,D/P,Paypal
    Terms of Trade: FOB,CFR
    Min. Order: 200 Piece/Pieces
    Delivery Time: 7 Days
    Packaging: L185*W165*H46mm Single gross weight: 21g
    Productivity: 600
    Brand: Isourceled
    Transportation: Ocean,Land,Air
    Place of Origin: Shen Zhen
    Supply Ability: 30000 pcs/month
    Certificate: CE, RoHS, FCC,CCC,PSE, ISO:9001
    Port: Shekou,YANTIAN

Basic Info

Model No.: GY0501

Product Description

The Smd 2835 CCT 536lm 5W AC COB Module is manufactured using a disc light board. For ceiling lamps, panel lights and floodlights are a whole 1.25MM thick aluminum substrate. Model: GY0501, current 0.037A, power: 5W, luminous flux 536 lm, luminous efficiency 105.1 lm/w, perfect heat dissipation Guaranteed service life. Smd 2835 CCT 536lm 5W AC COB Module light source conversion board is covered by 14 smd 2835 LED Lamp beads. Rate, white light source, guarantees absolutely uniform illumination, no flash, very good lighting effect, 5W ceiling lamp module can be directly installed on indoor ceiling and ceiling lamp panels, soft light, white, energy saving.

Smd 2835 CCT 536lm 5W AC COB Module video.


Product Characteristics of Smd 2835 CCT 536lm 5W AC COB Module.

Lighting Chart of Smd 2835 CCT 536lm 5W AC COB Module

The picture above is a real shot of the Smd 2835 CCT 536lm 5W AC COB Module.

1. Smd 2835 CCT 536lm 5W AC COB Module consists of 14 lessons of large area coverage of LED beads, white light source.

2. linear constant-current IC control, photoelectric integration, stable performance, reliable, long life.
3. Three-stage integrated circuit design, the power change rate is within ±5% when the input voltage fluctuates between 220-240vac;
Constant power over voltage current protection function.
4. Overtemperature protection function, IC will automatically reduce the output current to control the temperature rise of the substrate ,
when the substrate temperature is too high.
5. Using PCT2835 patch LED bead, color rendering index is more than 80.
6. There is no EMI, through the CCC, CE, EMC, LVD, SAA, UL, FCC, ROHS certification, etc.
7. No ultraviolet , electromagnetic wave radiation.
8. The size of 5W PCB board can be customized according to customer requirements.
9. No need to drive, wiring can be, 3 years replacement, full light, no flash screen.


Scope of application

Smd 2835 CCT 536lm 5W AC COB Module


Application scope of Smd 2835 CCT 536lm 5W AC COB Module:

Ceiling lamp, panel lamp, ceiling lamp, industrial and mining lamp, street lamp, LED down lamp, fluorescent lamp, projection lamp, etc.


Lighting Chart of Smd 2835 CCT 536lm 5W AC COB Module

Lighting Chart of Smd 2835 CCT 536lm 5W AC COB Module


Technical parameters of Smd 2835 CCT 536lm 5W AC COB Module:

Type

GY05-01

Input Voltage

AC220-240V 50HZ

Input Current

0.04A

Power

5W

Power Factor

0.6

Insulation Class

ACW>2KV

Operating tempeture

-20~45℃

luminous

536 lm

luminous efficiency

103.9 lm/w

Color temperature

5000K-6500K

Color rendering index

82

Size

Φ71*75mm

Weight

21 g

Thermal Conductivity

1.0W/m.K

Installation Notes:
Smd 2835 CCT 536lm 5W AC COB Module

installation guide:

Smd 2835 CCT 536lm 5W AC COB Module


1. Clean the installation surface, evenly apply the heat-conducting silicone grease to the bottom of the LED module, and fix the LED module and radiator with screws.

2. Attach the lens and screw it in place.

3. Ac 220V power supply is introduced for power test.

4. It is recommended to use an insulating gasket at the bottom of the screw.

Smd 2835 CCT 536lm 5W AC COB Module base plate picture


Use advice

1) This product has over temperature protection function, when the whole lamp temperature is too high, IC will automatically reduce the power to control the temperature rise,

it is suggested to choose qualified high quality radiator.When the ambient temperature is 25℃, the Tc temperature at the temperature measurement point on the

substrate surface should be <60℃.When the ambient temperature is 50℃, Tc<85℃.
